Main Page
|
Choose Your Languages:
Toggle navigation
CORPORATE
About Us
Ethics And Human Rigths
Integrity And Transparency
Innovation and Technology Usage
Industry And Trade Business Ethics
Social Sustainability
Sustainability
Supply Chain Responsibility
Community and Local Contributions
PRODUCTS
BRANDS
Go to brands page
BRANDS
QUALITY
NEWS
CONTACT US
PRODUCTS
Brands Page
AlphaRoyal1350
10
14
General Information
Category
Gold
Caratage
10K-14K
Color
Yellow
Color Shade
Light Yellow
Typology
Alloys For Gold
Production Process
İnvestment Casting
Density [cm
3
]
12,9
Solidus [°C]
797
Liquidus [°C]
850
As cast hardness [HV]
135
Ingredient
Ag
Cu
Zn
Ni
Deoxidant
Grain Refiner
Other
Typical Applications
General Characteristics
As Cast Grain Size [µm]
615
Color Coordinates
L*
91
a*
2,15
b*
19,05
c*
19,17
Mechanical Caracteristics
Tensile Strength (Rm) [MPa]
310
Yields strength (Rp0.2) [MPa]
170
Elongation Rupture (A) [%]
48
As cast Hardness [HV]
135
Hardness after 70% area red. [HV]
285
Hardness after annealing [HV]
140
Hardness after age-hardening [HV]
220
Casting Processing Parameters
Pre-mixing temperature [°C]
1050
Casting Temperatures
Metal [°C]
Flask [°C]
Thin (below 0.5 mm )
970
-
1010
660
-
720
Medium ( from 0.5-1.2 mm)
970
-
950
600
-
660
Thick (Thick 1.2 mm)
930
-
950
540
-
600
Trees without stones
After casting, cooling time for the flaks is 15 m
Stone-in-place casting trees
After casting, cooling time for the flaks is 45 m
Pickling :
Sulphuric acid (%10) - 5 min - 50°C
Age Hardening Processing Parameters
Single step age-hardening treatment
Temperature [°C]
Time [min]
Quenching
Age-hardening
Age-hardening
250
100
Cooling in furnuce
12
product in your basket.
see product
Selected Products
Compare
